Mudvac

A versatile and modern solution for liquid and mud waste.

Redefining Suction

The Mudvac features a stainless steel VTS tower, liquid ring vacuum system. This provides a high tolerance to carryover as well as a quiet and powerful combination of airflow and vacuum. Capable of handling everything from septic tanks to drill mud and even minor service locating.

Rugged Construction

VTS build specification
provides long term trouble

Simple operation

Minimal training required
for safe and efficient
operation.

Easy to Maintain

More time on the job, less
time in the workshop.

Fit for Purpose

The Mudvac has been thoroughly and continuously refined to ensure that it is perfectly suited to industrial and sludge waste applications. If you deal with car wash waste, drill muds and heavy sludges rest easy in the knowledge that VTS have created the solution for you!

Specs

Capacity
6,000

Size
4x2

Cab Chassis
Isuzu

Engine
Isuzu FVD 300hp 4x2 with auto transmission

Extras
N/A

Barrel
8mm Mild Steel

Compliance
AS1210 CL3 Hazard level B and AS4343 compliant barrel

Tipping
Hydraulic tipping and full rear door

Vacuum Pump
600 CFM liquid ring vacuum pump, hydraulically driven

Fresh Water System
1,400 litres of fresh water with Comet HP water pump

Vacuum Pressure
Vac tested to -101kpa, pressure tested to 100kpa

Inlet Valve
Fully rebuildable Molex inlet valve

Manifold
Stainless steel separator and manifolding

Air Bags
Rear airbag suspension
Capacity
10,000

Size
6x4

Cab Chassis
Volvo

Engine
Volvo FE 350 HP 6x4

Extras
Volvo Connect app provides vehicle performance and tracking data

Barrel
8mm Mild Steel

Compliance
AS1210 CL3 Hazard level B and AS4343 compliant barrel

Tipping
Hydraulic tipping and full rear door

Vacuum Pump
600 CFM liquid ring vacuum pump, hydraulically driven

Fresh Water System
1,400 litres of fresh water with Comet HP water pump

Vacuum Pressure
Vac tested to -101kpa, pressure tested to 100kpa

Inlet Valve
Fully rebuildable Molex inlet valve

Manifold
Stainless steel separator and manifolding

Air Bags
Rear airbag suspension

Our most stubborn job used to take over 1 hour, with the Mudvac we pump it in 17 minutes.

Knowledge Hub

We know how hard it is to find reliable information in the liquid waste industry! Check out our knowledge hub to keep you and your business on the cutting edge.

Whenever there is a need, we have a solution

What about custom?

Of course we are also capable of a diverse range of custom builds. If you have a need not addressed by our standardised range, please get in touch to discuss the details of your build.
